This is a smart 2 Wheel Robot Car Chassis for making movable robot. This is a complete package for your robot with including: an acrylic base with two gear motors, two compatible wheels, a ball caster, and other accessories. The Arduino Uno R3 and Motor Driver Module can be easily set in this robot chassis.
Package Contains:
- An Acrylic Base
- 2 x 65mm Rubber Wheel
- 2 x Mini DC Gear Motor
- 2 x Fasteners
- 1 x Nylon all-direction wheel
- 1 x Four AA Battery Holder (Battery not included)
- All necessary screw and nut
Application:
- Obstacle Avoiding Robot
- Line Following Robot
- Remote Controlled Car
- Any Kind of Toy Car.
DC motor specification:
- Rated Voltage: 3-6V DC.
- Unloaded speed: 120 RPM.
- Load current: 190 mA (250 mA MAX).
- maximum torque: 800 g. Cm min.
Chassis Specification:
- Dimensions: 7.72 in x 4.13 in x 0.12 in (19.6 cm x 10.5 cm x 0.3 cm)
- Weight: 14.29 oz (405 g)
Wheel specification:
- Width:26mm
- Diameter:65mm
To learn how to assemble 2 Wheel Robot Car Chassis watch our tutorial from youtube.
Our Youtube Channel: Naba Tech World
