This is the legendary 775 Motor DC Motor in Bangladesh. Very Powerful and High Torque DC Motor. Though this motor operates in DC 12V to 36V but you will be surprised to see the power of this motor. Because of that this motor is now very popular to hobbyists. This motor has Ball bearing in both terminal of the shaft and built-in cooling fan. High torque with wide operating voltage 12~36 Vdc with speed of 21000 RPM. Suitable for motor tools application and DIY projects. 775 Motor is now available in Bangladesh.
Application:
- High Power Drill Machine
- Angle Grinder
- DC Water Pump
- Saw Machine
- Sanding Machine etc.
- Brand new and high quality
- Double Ball Bearing
- Shaft Diameter: Approx. 5 mm
- Shaft length: Approx. 17 mm
- Body length: Approx. 66.7 mm
- Front steps diameter: Approx. 17.4 mm
- Former high level: Approx. 4.7 mm
- Body diameter: Approx. 42 mm
- Motor Overall Length: Approx. 98 mm
- Diagonal installation pitch: Approx. 28.8 mm
- Mounting hole size: M4
- Mounting hole: 2
- Cooling fan: Yes
- Rated voltage: 24 V (Max. 36V)
- Current Rating: 0.16 A
- Rated Speed: 3500--9000 RPM
Watch this video to learn How to make a Drill Machine using 775 DC Motor: Video Link
