[vc_row][vc_column][vc_tta_tabs][vc_tta_section title=”Description” tab_id=”description”][vc_column_text]This is an high speed CMOS 8-BIT SHIFT REGISTERS/OUTPUT LATCHES (3-STATE) fabricated with silicon gate C2MOS technology.This device contains an 8-bit serial-in, parallel-out shift register that feeds an 8-bit D-type storage register. The storage register has 8 3-STATE outputs. Separate clocks are provided for both the shift register and the storage register.The shift register has a direct-overriding clear,serial input, and serial output (standard) pins for cascading. Both the shift register and storage register use positive-edge triggered clocks. If both clocks are connected together, the shift register state will always be one clock pulse ahead of the storage register.All inputs are equipped with protection circuits against static discharge and transient excess voltage.[/vc_column_text][/vc_tta_section][vc_tta_section title=” Specifications” tab_id=”specifications”][vc_column_text]
- Supply Voltage: -0.5 to 7 V
- DC Input Voltage :-0.5 to VCC 0.5 V
- DC Output Voltage :-0.5 to VCC 0.5 V
- DC Input Diode Current :± 20 mA
- DC Output Diode Current: ± 20 mA
- DC Output Current :± 35 mA
- DC VCC or Ground Current :± 70 mA
- Power Dissipation :750 mW
